UNA-OP39-500
UNA
8528591090
Product Description
Front side maintenance Booth LED Commercial Digital Screen
Product Features:
1. Cabinet size for rental screen is 500x500mm or 500x1000mm
2. Pixel pitch ranges from P2.6, P2.976, P3.91 or P4.81
3. Slim and light design,we use ultra-slim die-casting aluminium cabinets, weight is lighter and best for heat dissipation, easy to transport and install
4. High definition, Rental LED digital signage with smaller pixel pitch that gives a higher resolution,perfect for close viewing distance
5. True color and high brightness, with SMD technology and 3 in 1(RGB) light-emitting diode that make indoor LED screen gives a full-color ad vivid show
6. Long lifespan: 100,000Hours,it could be used for 22 years if run at 12 hours a day, 7 days a week
7. Application: Outdoor events, promotional activities, stage speech events,concerts,or any seasonal affairs, etc
8. Installation: Outdoor, for rental business
9. Maintenance: Front-side access, or Rear-side access
Specifications：
| Pixel pitch(mm) | 2.6 | 2.976 | 3.91 | 2.976 | 3.91 | 4.81 | ||||||
| LED type(SMD) | 2020 | 2020 | 2020 | 2020 | 2020 | 2020 | ||||||
| Module Size(mm) | 250x250 | 250x250 | 250x250 | 250x250 | 250x250 | 250x250 | ||||||
| Module Resolution(dot) | 96x96 | 84x84 | 64x64 | 84x84 | 64x64 | 52x52 | ||||||
| Module Pixel | 9216 | 7056 | 4096 | 7056 | 4096 | 2704 | ||||||
| Pixel Density(dot/㎡) | 147456 | 112896 | 65536 | 112896 | 65536 | 43264 | ||||||
| Best View Distance | >2.5m | >3m | >4m | >3m | >4m | >5m | ||||||
| Cabinet size(W*H) mm | 500x500 | 500x1000 | 500x500 | 500x1000 | 500x500 | 500x1000 | 500x500 | 500x1000 | 500x500 | 500x1000 | 500x500 | 500x1000 |
| Cabinet Resolution(dot) | 192x192 | 192x384 | 168x168 | 168x336 | 128x128 | 128x256 | 168x168 | 168x336 | 128x128 | 128x256 | 104x104 | 104x208 |
| Usage | Indoor / Rental | Outdoor / Rental | ||||||||||
| Water proof IP rate | IP31 | Front: IP65; Rear:IP54 | ||||||||||
| Brightnees(nits) | <1100 | <5000 | ||||||||||
| View angle | H: 160° / V: 160° | |||||||||||
| Gray scale | 16 bit | |||||||||||
| Refresh Rate | 1920Hz / 3840Hz | |||||||||||
| Diving Mode | 1/16 scan | |||||||||||
| Lifespan(H) | >100 000 | |||||||||||
| Power Comsumption(max.) | 550 | 600 | 800 | |||||||||
| Power Comsumption(ave.) | 180 | 200 | 266 | |||||||||
Environment：
| Working Temperature | –20℃ ～ + 60℃ | |||||||||||
| Working Humidity | 10% ～90% | |||||||||||
| Storage Temperature | –35℃ ～ + 85℃ | |||||||||||
| Storage Humidity | 10% ～90% | |||||||||||
Material：
| Cabinet | Die-cast aluminium | |||||||||||
| Maintenance | Front-side / Rear-side access | |||||||||||
| LED chip | Nationstar / King light | |||||||||||
| Power supply | Meanwell / G-energy | |||||||||||
| Controlling system | Novastar / Linsn / Colorlight | |||||||||||
| Installation | Free standing / Hanging | |||||||||||
Service:
Can provide samples for testing and approval.
Can speed up production to meet customers' market demand.
Installation instructions, customized design or colors are available.
Could print customers' LOGO on the frame with digital file from clients.
Warranty is 2 years, with extra spare parts for maintenance.
Assist customers to purchase with any other concerning products.
Why choose us?
The skilled manufacturer, experienced engineers and strict QC have earned a good reputation.
Advanced production equipments.
A professional sales team to guarantee samples quality, mass-production shipments and After-sales service.
Production capacity is the guarantee.
Shipping and payment:
Trade Terms: EXW,FOB,or CIF, DDU, etc
Payment terms: By T/T or Western Union, 30% deposit and 70% balance before shipment.
Lead-time: Around 15 days depend on order quantity.
MOQ: Sample order is accepted.
Package: Bubble bag + Flight Case
Shipping: by international express as UPS, TNT, DHL, FEDEX, by air or by Sea.
